7STA1280 Motorized Translation Stages

Request a Quote

Features

Equipped with a stepper motor and a DB9 connector, ensuring seamless integration with 7SC series motion controllers for automated positioning.
Cost-effective design, making it suitable for applications with lower precision requirements while maintaining reliable performance.
The precision-ground lead screw delivers high resolution and stable linear motion.
A robust dovetail guide provides high load capacity and smooth operation.
A high-quality elastic coupling minimizes backlash, ensuring synchronized motion with low noise.
For added flexibility, the built-in handwheel enables manual fine-tuning whenever required.

Specifications

Model	7STA1280
Travel（mm）	80
Screw lead (mm)	1
Resolution (at 8 microsteps) (mm）	0.000625
Maximum speed (at 2 microsteps)（mm/s）	10
Motor type	42 stepper motor (1.8°)
The Maximum static torque（N·m）	0.4
Rated working current（A）	1.7
Central load（kg）	20
Weight（kg）	1.35
